Beschreibung
Wesentliche Merkmale
- 12-Kern-Faser-Kapazität
Designed to accommodate up to 12 single fibers, suitable for standard-density fiber management requirements. - SC/APC Connector Compatibility
Angled 8° APC interface minimizes return loss and improves signal quality, ideal for high-performance optical networks. - Optimized Fiber Routing
Built-in fiber management paths maintain proper bend radius and prevent micro-bending losses. - Langlebige Konstruktion
Made from flame-retardant, impact-resistant materials to protect fiber splices over long-term operation. - User-Friendly Installation
Modular design allows quick splicing, inspection, and re-entry, reducing installation and maintenance time.
Technische Daten
| Parameter | Spezifikation |
|---|---|
| Produktname | Fiber Optic Splice Tray SC/APC-12 Core |
| Faser-Kapazität | 12 Kerne |
| Stecker Typ | SC/APC |
| Faser-Typ | Single-mode (G.652D / G.657A) |
| Typische Einfügedämpfung | ≤ 0.3 dB (industry average, 2025) |
| Typische Rückflussdämpfung | ≥ 60 dB (SC/APC standard) |
| Material | Flammenhemmendes ABS/PP |
| Betriebstemperatur | -40°C bis +75°C |
| Einrichtung | ODF, Spleißverschluss, Anschlussdose |
Performance data is based on current optical communication standards and typical field applications.
Anwendungsszenarien
The Fiber Optic Splice Tray SC/APC-12 Core is suitable for a wide range of applications, including:
- Glasfaser-Zugangsnetze (FTTH - Fiber to the Home)
- Telecom central offices and transmission nodes
- Optische Verteilerkästen (ODF)
- Glasfaserabschlussdosen und Spleißverschlüsse
- Projekte zur Systemintegration und Netzerweiterung
Its stable optical performance makes it especially suitable for long-distance and high-bandwidth transmission environments.
Qualität und Produktionssicherung
Backed by Fenxi Optoelectronics Technology’s experienced R&D and quality management teams, each splice tray undergoes strict material selection and production control. The product is designed to meet current international fiber optic deployment requirements, ensuring long-term reliability and consistent performance.
