Beschreibung
Technische Leistungsmatrix
Our manufacturing process is optimized to meet the following industry-standard benchmarks, ensuring consistency across every unit:
| Parameter | Spezifikation | Netzwerk-Vorteil |
| Stecker Typ | LC/UPC to SC/UPC | SFF-to-Standard hybrid design |
| Faser-Kategorie | Einmoden-Duplex (SM/DX) | Full-duplex bidirectional support |
| Einfügedämpfung | $< 0,3 \text{ dB}$ | Minimal power loss for the fiber link |
| Rückflussdämpfung | $\geq 50 \text{ dB}$ (UPC) | Excellent signal clarity for digital data |
| Wellenlänge | 1310nm / 1490nm / 1550nm | Universal OS2 single-mode support |
| Bandbreite | $\pm 40\text{nm}$ | Stable performance across wavelengths |
| Zugfestigkeit | $\geq 200 \text{ N}$ | Rugged build for intensive installation |
| Dauerhaftigkeit | $\geq 1000$ mal | Long-life cycle for repetitive patching |
| Material der Jacke | LSZH (Gelb) | Fire-retardant and smoke-safe |
Key Benefits for Network Infrastructure
1. Flexibilität der hybriden Schnittstelle
This cable provides an essential transition between the Small Form Factor (SFF) LC connector, ideal for high-density switches, and the SC connector, which is favored for its robust push-pull mechanism in terminal equipment and wall outlets.
2. Full-Duplex Data Throughput
Die Duplex (DX) configuration consists of two color-coded fiber strands, enabling simultaneous two-way communication. This design simplifies cable routing for 10G/40G Ethernet applications that require dedicated transmit (TX) and receive (RX) paths.
3. Mechanical Resilience
With a pull strength rating of $\geq 200\text{N}$, these jumpers are designed to handle the physical strain of being routed through vertical conduits and crowded cable trays without risking micro-bends or core fractures.
4. International Safety Compliance
Die LSZH (raucharm und halogenfrei) jacket is mandatory for indoor installations. In the event of extreme heat, it ensures minimal smoke and no toxic halogen emissions, protecting both critical hardware and site personnel.
Quality Assurance & Logistics
-
100% Factory Tested: Every cable is individually verified for Insertion Loss (IL) and Return Loss (RL) before packaging.
-
Einhaltung von Normen: Meets Telecordia GR-326-CORE and IEC international fiber optic standards.
-
Inventory & Lead Times: We carry substantial stock of common lengths (1m to 30m) to ensure rapid fulfillment for project-based orders.
-
OEM-Anpassung: Available in custom lengths, 2.0mm or 3.0mm jacket diameters, and personalized labeling to meet specific contractor requirements.
