Beschreibung
🚀 Key Advantages for Modern Infrastructure
-
Weight-Optimized Construction: The lightweight polymer chassis reduces mechanical stress on high-density ODF ports, preventing port sag over long-term deployments.
-
EMI/RFI Immunity: The all-plastic internal retention system is completely non-conductive, making it the safest choice for environments near high-voltage power lines or sensitive industrial equipment.
-
Precision 8° APC Geometry: Each unit is designed to hold the zirconia ferrule at a precise 8-degree angle, forcing back-reflections into the cladding and ensuring a Return Loss of ≥60dB.
-
Snap-Lock Reliability: The high-tenacity plastic internal clips provide an audible “click” during assembly, confirming that the ferrule is securely seated against the internal spring for constant physical contact.
-
Climate-Resilient Materials: Utilizing engineering-grade thermoplastics that resist brittleness, these connectors maintain their latching strength across a wide temperature spectrum from -40°C bis +75°C.
📉 Core Performance Metrics
| Performance Pillar | Industry Standard | Our Specification |
| Faser-Kategorie | Single-mode (G.652.D / G.657.A) | Optimized for OS2 |
| Termination Style | All-Plastic Crimp | Jacket + Kevlar Integration |
| Typical Loss | ≤ 0,30 dB | ≤ 0.20 dB |
| Reflection Suppression | ≥ 55 dB | ≥ 60 dB |
| Zugwiderstand | ≥ 70N | ≥ 100N (3.0mm) |
| Einhaltung der Sicherheitsvorschriften | UL 94V-0 | RoHS & REACH Verified |
💡 Practical Application & Assembly Insights
Q: In what specific scenarios is “All-Plastic” better than “Metal Stop” models?
A: All-Plastic is the superior choice for high-humidity coastal regions where salt-spray can corrode even plated metals over time. It is also the preferred “Standard Build” for FTTH drop-cables where cost-per-subscriber is a primary project KPI.
Q: How does this kit manage the transition between 2.0mm and 3.0mm cables?
A: We provide a dual-stage tapered boot. The boot’s internal diameter is designed to grip 2.0mm leads snugly while having enough elasticity to expand and provide full bend-radius protection for thicker 3.0mm jacketed cables.
Q: Can these be used with automated polishing machines?
A: Absolutely. The external dimensions and ferrule protrusion are manufactured to micron-tolerances, making them fully compatible with all standard SC polishing fixtures for high-speed factory production.
Q: Is the internal spring also plastic?
A: No. While the housing and retention clips are plastic, we utilize a high-carbon stainless steel spring to ensure that the 1.2kg of mating force required for stable physical contact never degrades over the 1,000+ cycle lifespan of the connector.
