Description
Key Features and Benefits
- LC/APC Duplex Interface
Duplex design supports two fiber connections in one compact adapter for transmit and receive signals. - Low Return Loss Performance
8° APC polishing minimizes back reflection, suitable for high-speed and long-distance optical links. - Precision Alignment Sleeves
Zirconia ceramic sleeves ensure accurate fiber core alignment and consistent optical performance. - High-Reliability Housing
Flame-retardant materials provide excellent mechanical strength and long-term durability. - Standard Panel Mounting
Compatible with ODFs, patch panels, and fiber termination boxes for easy integration.
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Name | Fiber Optic Adapter LC/APC-DX |
| Connector Type | LC/APC Duplex |
| Fiber Mode | Single-mode (OS2) |
| Typical Insertion Loss | ≤ 0.2 dB (industry benchmark, 2025) |
| Typical Return Loss | ≥ 60 dB (APC standard) |
| Alignment Sleeve | Zirconia Ceramic |
| Housing Material | Flame-retardant Plastic |
| Operating Temperature | -40°C to +75°C |
| Mounting Type | Panel / ODF Mount |
All parameters are based on current optical communication industry standards and typical installation environments.
Application Scenarios
The Fiber Optic Adapter LC/APC-DX is widely applied in:
- Telecommunications access and backbone networks
- FTTH distribution systems
- Data centers and enterprise networks
- Optical Distribution Frames (ODF)
- System integration and network expansion projects
Its low reflection characteristics make it especially suitable for high-bandwidth and long-distance optical transmission systems.
Manufacturing and Quality Assurance
Fenxi Optoelectronics Technology combines experienced R&D teams with strict quality management processes. Each LC/APC-DX adapter undergoes optical performance testing and mechanical reliability inspection to ensure compliance with current fiber optic deployment standards.
