Description
What This Cable Brings to Your Network
-
Long-Reach Single-Mode Performance
Optimized for 1310 nm and 1550 nm wavelengths, enabling links from short patching all the way to kilometer-scale connections. -
High-Density, Low-Clutter Design
MPO technology dramatically reduces cable bulk compared with running eight separate LC patch cords. -
Perfect for 100G & 400G Optics
Fully compatible with PSM4, DR4, and breakout transceivers, making it ideal for leaf-spine and DCI architectures. -
Factory-Terminated Precision
Each connector is polished, aligned, and tested to ensure stable optical budgets and low insertion loss.
Key Technical Data
| Item | Specification |
|---|---|
| Fiber Type | OS2 Single-Mode (9/125 µm) |
| Fiber Count | 8 |
| MPO Connector | 8-fiber MPO / MTP |
| LC Connectors | 8 × LC |
| Operating Wavelengths | 1310 nm / 1550 nm |
| Insertion Loss | MPO ≤ 0.35 dB, LC ≤ 0.30 dB |
| Return Loss | ≥ 50 dB |
| Cable Jacket | LSZH or PVC |
| Operating Temperature | −10 °C to +70 °C |
| Compliance | IEC, TIA, RoHS, REACH |
Where MPO-LC-SM-8Core Is Used
This cable is widely deployed in:
-
Leaf-spine data center architectures
-
Data Center Interconnect (DCI)
-
Telecom and metro networks
-
400G single-mode switch deployments
-
High-density optical distribution frames
Professional Q&A
Q1: Is this cable suitable for long-distance transmission?
Yes. OS2 single-mode fiber supports distances of several kilometers, depending on the transceiver.
Q2: Can it be used with 400G modules?
Yes. It works with 400G DR4 and PSM4 optics using LC breakout connections.
Q3: What is the advantage of MPO to LC instead of MPO to MPO?
MPO-LC allows you to connect directly to standard LC-based transceivers and panels without extra conversion cables.
Q4: Can polarity be customized?
Yes. MPO polarity types (A, B, or C) can be specified to match your network design.
