Description
Designed for Demanding Applications
-
Maximized Signal Purity: The 8° angled end-face reduces back reflection to >60 dB, preventing interference in analog and RFoG systems.
-
High-Density Fit: SC connectors offer a secure, stable connection in space-conscious panels and distribution frames.
-
Factory-Certified Performance: Each pigtail is individually tested for insertion loss, return loss, and end-face geometry to ensure compliance.
-
Future-Ready: Supports wavelengths from 1310 nm to 1625 nm, compatible with CWDM/DWDM and PON technologies.
Key Specifications at a Glance
-
Model: SC/APC 12-Core Single-Mode Pigtail
-
Fiber Type: G.657.A1 (Bend-Insensitive)
-
Insertion Loss: < 0.3 dB
-
Return Loss: > 60 dB
-
Operating Temp: -40°C to +85°C
-
Jacket: LSZH, Green (APC Standard)
Technical Q&A
Q: When is SC/APC absolutely necessary instead of SC/UPC?
A: SC/APC is critical in any analog or RF-over-fiber application (e.g., CATV, satellite), and in PON networks (GPON, XGS-PON) where high return loss prevents upstream laser interference and ensures stable subscriber service.
Q: Is the green connector standard for APC?
A: Yes, the green strain relief and body are industry-standard identifiers for APC polish, allowing quick visual differentiation from blue UPC connectors.
Q: Can this pigtail be used in existing UPC infrastructure?
A: No. APC and UPC connectors are not physically compatible. Mating them can damage both end-faces. Ensure all connecting adapters and equipment ports are also APC-type.
