🌪️ Harsh Environment Testing: Proven to Survive
We subjected our FC/UPC 12-Core Pigtail to rigorous industrial stress tests:
| Test Condition | Result |
|---|---|
| Temperature Cycling | -40°C to +85°C (100 cycles) → No signal degradation |
| Titreşim Direnci | 5-2000Hz, 10G acceleration → No connector loosening |
| Dust & Water | IP65-rated enclosure → No signal loss after 1000 hours of dust exposure |
| Çekme Dayanımı | 1500N pull test → No fiber breakage |
These tests confirm the pigtail’s ability to maintain performance in the most demanding industrial environments.
⚙️ Industrial-Grade Design Features
1. FC/UPC Connector: Secure Mating for Vibration-Prone Areas
The FC/UPC connector’s threaded locking mechanism ensures a tight, vibration-resistant connection—critical for factory floors and oil platforms where machinery movement can dislodge push-pull connectors.
2. 12-Core Multimode: High Bandwidth for Industrial IoT
With support for 850nm/1300nm wavelengths and ±40nm bandwidth, this pigtail delivers 10Gbps transmission over 300m, enabling real-time data transfer from IoT sensors to control rooms.
3. Heavy-Duty LSZH Jacket: Protection Against Mechanical Damage
The thick LSZH jacket resists abrasion, chemical exposure, and UV radiation, ensuring a 10+ year lifespan in outdoor and industrial settings.
🛠️ Technical Specifications
| Parametre | Detaylar |
|---|---|
| Ürün Adı | FC/UPC 12 Çekirdekli Çok Modlu Fiber Pigtail |
| Konektör Tipi | FC/UPC (threaded locking) |
| Elyaf Tipi | Multimode (OM3/OM4) |
| Çekirdek Sayısı | 12 |
| Gerilim Dayanımı | ≥ 1500N |
| Dayanıklılık | ≥ 2000 mating times |
| Ekleme Kaybı | ≤ 0,35dB |
| Geri Dönüş Kaybı | ≥ 25dB |
| Çalışma Sıcaklığı | -40°C ila +85°C |
| Malzeme | Heavy-Duty LSZH |
🏭 Ideal Industrial Applications
- Factory Automation: Connects PLCs, robots, and sensors in automotive and manufacturing plants
- Oil & Gas: Supports data transmission from wellhead sensors to control centers
- Outdoor Utilities: Powers smart grid and traffic management systems
- Mining: Withstands dust and vibration in underground mining operations
🛡️ FAQ for Industrial Engineers
Q1: Is this pigtail compatible with existing FC/UPC adapters?
A: Yes—our FC/UPC connectors are fully compatible with standard industry adapters, making retrofits seamless.
Q2: How do I clean FC/UPC connectors in dusty environments?
A: Use a lint-free wipe with isopropyl alcohol to clean the ferrule, and blow dust away with compressed air before mating.
Q3: Can this pigtail be buried underground?
A: For direct burial, we recommend our armored version with water-blocking gel. Standard units are suitable for conduit installation.
