Açıklama
Data-Driven Technical Specifications
Our manufacturing process ensures every jumper meets the following rigorous performance standards:
| Özellik | Industrial Specification | Business Advantage |
| Konektör Tipi | ST/UPC to SC/UPC | Secure metal-to-plastic hybrid link |
| Elyaf Kategorisi | Single Mode (SM/SX) | Optimized for long-distance OS2 stability |
| Ekleme Kaybı | $< 0,3 \text{ dB}$ | Minimal signal attenuation for long paths |
| Geri Dönüş Kaybı | $\geq 50 \text{ dB}$ (UPC) | Ensures high digital signal integrity |
| Dalga Uzunluğu | 1310nm / 1490nm / 1550nm | Full spectrum compatibility for SM optics |
| Bant Genişliği | $\pm 40\text{nm}$ | Spektral kaymalar boyunca istikrarlı performans |
| Gerilim Dayanımı | $\geq 200 \text{ N}$ | Superior durability for vertical routing |
| Dayanıklılık | $\geq 1000$ zamanlar | Built for repeated industrial use |
| Ceket Malzemesi | LSZH (Düşük Dumanlı Sıfır Halojen) | Compliant with global fire safety codes |
Why This Hybrid Model is the B2B Choice
1. Robust Industrial Connectivity
Bu ST/UPC end features a nickel-plated metallic housing with a spring-loaded twist-lock, offering maximum resistance to mechanical vibration. This is paired with the SC/UPC end, known for its user-friendly push-pull mechanism, providing a stable and reliable interface for standard networking hardware.
2. Verified Optical Precision
With a tested insertion loss of less than 0.3dB and return loss exceeding 50dB, this cable maintains the high power budget required for critical 10G/40G data links. Each unit is 100% factory tested to ensure zero-defect delivery for large-scale projects.
3. Safety-First Infrastructure
Safety is a priority for B2B procurement. Our yellow jackets are made of LSZH material, which emits limited smoke and zero toxic halogens during a fire, protecting both your personnel and your high-end electronic equipment from corrosive damage.
4. Extreme Durability
With a tension strength of $\geq 200\text{N}$ and a mating durability of 1000+ cycles, these jumpers are designed to withstand the physical stress of installation in dense conduits and frequent re-patching in industrial environments.
B2B Procurement FAQ
-
Q: Is this “Blue” ST/UPC cable compatible with “Green” APC ports?
-
A: No, UPC and APC end-faces have different geometries. Mixing them creates an air gap that results in high signal loss. Always match Blue (UPC) to Blue ports.
-
-
Q: Can you provide 3D interferometry reports for bulk orders?
-
A: Yes, as a professional B2B partner, we provide comprehensive test reports, including IL, RL, and 3D geometry verification, to ensure all wholesale shipments meet your project’s high standards.
-
-
Q: What is the benefit of the LSZH material for enterprise use?
-
A: LSZH is mandatory for many modern building codes. It ensures that in the event of a fire, toxic fumes are not released, making it the standard choice for data centers, hospitals, and office buildings.
-
